Wayne Dalton Garage Door Torquemaster Adjustment

Savin the day fixes his torque master type garage door spring.

Wayne dalton garage door torquemaster adjustment.

View and download wayne dalton torquemaster 9100 installation instructions and owner s manual online. How to level a garage door with wayne dalton torquemaster springs. Torquemaster 9100 garage door opener pdf manual download. This specialty spring is made only by wayne dalton for their torquemaster tms garage door system.

Replacement springs for wayne dalton garage doors using the torquemaster spring system. Wayne dalton torquemaster plus is a spring system used on garage doors. Torquemaster systems use a spring system that is enclosed inside a hollow torque tube that mounts on the header above the garage door opening. It is similar to a standard.

Failure to clamp track can allow door to raise and cause severe or fatal injury. Garage door springs can be dangerous to work with. Torsion springs fit inside the shaft instead of sliding over the shaft lifting the door. Step 1 slide the right and left hand springs perch end first into the torque tube fig.

One popular option the torquemaster plus system provides is the ability to replace just the springs in the system when maintenance is needed instead of having to replace the whole system. Lift the spring tube assembly up and align the center bushing into the center bracket. The torquemaster double spring counterbalance system is appli cable for door weights greater than 115 lbs. Torquemaster 9400 torquemaster 9600 torquemaster plus 9100 torquemaster plus 9400 torquemaster plus 9600.

If you are installing a wayne dalton torsion garage door for the first time adjusting it is the last task you will do after installing the vinyl weather stripping. Adjust the cable length until the door is level. Lift the door and check the balance. Align the internal hex of winding mechanism with the right hand side winding shaft and slide the mechanism onto the shaft until the mechanism is flush with ratchet bracket.

If the garage door is not level you will need to adjust the length of the cable on the side that is too high. If the door lifts by itself or if it is hard to pull down you will need to unwind the springs. Beginning with the right hand side turn the pawl knob to the upper position. Holding the end of the cable with a vise grip loosen the setscrew on the cable drum.
